The Palmer PAN02 PRO is an active direct input box featuring exceptional additional functions. These include an unbalanced XLR input and a three-way attenuator with -10, -20, -30 dB settings, along with a switchable 12 dB gain, leading to a maximum output voltage of +20 dBu.
The Groundlift switch features a "lift" position for toggling between "soft and hard grounding." A high-quality transformer within a Mumetal housing ensures a balanced output, designed specifically for this purpose. The PAN02 Pro can operate on either a 9 V battery or 48 V phantom power, with a dual-color LED indicating the power source.
Product type DI Boxes
Type active
Channels 1
Inputs 2
Input connectors 6.3 mm jack , XLR
Max. input level + 45 dBu
Input impedance -10 & -20 dB: 70 k Ohm(s) , -30 dB: 40 k Ohm(s) , 0dB & 12 dB: 1 M Ohm(s)
Input pad 0 dB, -10 dB, -20 dB, -30 dB
Outputs 1
THRU outputs/channel 1
Output connectors 6.3 mm jack , XLR
Max. output level + 20 dBu
Output impedance 600 Ohm(s)
Frequency response 20 - 20000 Hz
Transformer balanced Yes
Ratio 3.16:1, 10:1, 31.6:1, 1:4
Controls attenuator , battery/+ 48 V Power , Boost , ground lift
Operating voltage +48 V phantom power , 9 V block
Cabinet material sheet steel
Cabinet surface Powder coated
Width 116 mm
Depth 140 mm
Height 43.5 mm
Weight 0,85 kg
First-class Active Di-box
Unbalanced XLR Input
3-way attenuator (-10, -20, -30dB)
Switchable gain (12dB)
Max. Output voltage +20 dB
Soft ground lift
