Rated Power measured with 2 hours test with pink noise signal, 6dB crest factor, loudspeaker mounted on enclosure
Power on Continuous Program is defined as 3 dB greater than the Rated Power
Thiele and Small parameters measured with laser system withou preconditioning test
The notch around 400 Hz on the frequency response is typical of the measurement on IEC baffle
Due to continuing product improvement, the features and the design are subject to change without notice.
Nominal Diameter: 306 mm / 12 in
Nominal Impedance: 16 Ω
Rated Power AES: 25 W
Continuos Program Power: 50 W
Sensitivity @ 1W/1m: 92.3 dB
Voice Coil Diameter: 25 mm (1")
Voice Coil Winding Depth: 8 mm
Magnetic Gap Depth: 6 mm
Flux Density: 1.00 T
Magnet Weight: 270 g
Net Weight: 1.4 Kg
Magnet Type: Ferrite
Basket Material: Pressed Sheet Steel
Voice Coil Winding Material: Copper
Voice Coil Former Material
Kapton: Cone Material
Paper: Surround Treatment
No: Surround Material
Paper – Integrated
Dust Dome Material: Felt
